[Characteristics & functions]
Specifically designed for adjusting the 240 VIVID
functional settings conveniently.
Compact & lightweight.
Data settings can be saved and input to any other 240 VIVID model.
Gain: 1.AGC(Selectable AGC range from 6 to 30dB in 1dB steps), 2.Manual
fixed gain selectable from 6 to 30dB in 1dB steps
Shutter speed: 1.EI(Min. and Max. shutter speed range can be selected
manually from OFF to 1/100000(OFF1/60(N) or 1/50(P)),FL(1/120(N) or
1/100(D)), 1/250, 1/500, 1/1000, 1/2500, 1/5000, 1/10000, 1/20000,
1/50000, 1/100000.), 2.ES(Shutter speed can be selected manually from
the above mentioned 11 settings.)
Back light compensation: 5 selectable area settings
Setup level selection: control within a range of 0 to 50mV(7.5 IRE)
Video level: select either 75 IRE or 100 IRE
White balance: 1.ATW(Auto-tracking), 2.Fixed(Color temperature can be
selected from 3200K, 4400K, 5100K, and 8200K. Red and blue gain can be
finely adjusted separately.)
Gamma correction: select either 0.45 or OFF
Outline enhancer: both horizontal and vertical in 4 steps
Color/monochrome picture selection
Mirror image
Data save/delete
[Specifications]
Display: transflective STN LCD
Display light: Yellow-green LED
Max. #of characters per line: 20~4 lines
Power supply: DC{6V}10%(Use of power supply AD-603 or dry cell battery
AA(~4)is recommended.)
Battery life: à8h(display light ON),à100h(display light OFF)
Current: 50mA(display light ON)
Weight: 330g
[Accessory]
AD-603(Power supply), cable(1m) |
