Spec. download
|
[Characteristics
& functions]
Frame integration system (Slow shutter speed)
Ultra low light sensitivity
Wide ranging shutter speed
Controlable with hand-held remote controller
High vertical resolution
Simultaneous output of composite video & Y/C signals
Still picture
Shutter speed control
Manual gain control
Gamma correction (3 steps)
Iris lens control (open/auto)
Video/DC iris auto-select
Iris level control
[Specifications]
Effective pixels: 380k(N), 440k(P)
Resolution: 570TVL(H), 480TVL(V)
Minimum illumination: 0.00002 lx. F1.4
Gain control: MGC(8-38dB)
S/N ratio: 52dB
Shutter speeds: HI(OFF, 1/25, 1/250, 1/500, 1/1000, 1/2000[Sec.]), LO(1, 2,
4, 8, 16, 32, 64, 128, 256[Frame])
Gamma: 0.35/0.45/1.0
Weight: 150g(Controller 210g)
[Accessories]
no includo junto com a compra da
cmera
WAT-120N+RC(Controller)
WPDC12(DC plug)
AIC-G(Iris plug)
34CMA-R(C-mount adaptor)
Hex. wrench
[Options]
AD901-120/-230(Power supply),
MS50(Stand), B003(Bracket) |
