Characteristics & functions
Multi functions
Ultrahigh sensitivity
High resolution (540TVL)
EI control for FL mode
Color-rollingless AWB mode
Simultaneous output of composite video & Y/C signals
White balance control
Shutter speed control
Electronic iris
Flickerless mode
AGC
Back light compensation
Gamma correction
Video level switch(100 IRE / 75 IRE)
Video/DC iris auto-select
Iris level control
Specifications
Effective pixels: 380k(N), 440k(P)
Resolution: 540TVL
Minimum illumination: 0.05 lx. F1.2
S/N ratio: 50dB
Shutter speeds: EI(1/60(N) or 1/50(P)-1/100,000), (EI control for FL 1/60(N)
or 1/50(P)-1/100,000), FL, OFF, 1/250, 1/500, 1/1000, 1/2000, 1/4000,
1/10000
White balance: ATW/PWB/MWB/Preset(3200K, 4300K, 5100K, 6300K)
Gain control: AGC ON(HI:0-38dB, LO:0-32dB) / MGC(0-32dB)
Gamma correction: ON(0.45)/OFF(1.0)
Back light compensation: ON/OFF
Weight: 140g |
|
